<em>RIEGL</em> VMX-3HA

MOBILE LASER SCANNING
RIEGL VMX-3HA NEW

The RIEGL VMX-3HA is a High Speed, High Performance Dual Scanner Mobile Mapping System which provides dense, accurate, and feature-rich data at highway speeds. With 6,000,000 measurements and 800 scan lines per second, this turnkey solution is ideally suited for survey-grade mobile mapping applications.

<em>RIEGL</em> VMX-3HA

HIGH SPEED, HIGH PERFORMANCE
Dual Scanner Mobile Mapping System

Built for professionals in transportation, infrastructure, and environmental mapping, the VMX-3HA Mobile Mapping System combines speed, precision, and efficiency in one powerful system – ready to take on complex projects with confidence.

This powerful technology comprises two RIEGL VUX-3HA High Performance LiDAR Sensors and a high performance IMU/GNSS unit, housed in an aerodynamically-shaped protective cover.
Interfaces for up to 9 optional cameras enable complementation of the LiDAR data with precisely geo-referenced images.



What makes the VMX-3HA stand out?

360° Precision in Motion
 Whether you're mapping city streets or highways, the VMX-3HA delivers full-environment coverage with pinpoint accuracy – even at high speeds.

Ultra-Dense Data, Near and Far
 From fine pavement textures to overhead cables and distant vegetation, every detail is captured with clarity and depth.

Effortless Efficiency
 Maintain high point densities at faster platform speeds. The VMX-3HA keeps quality high and workflows smooth, even under demanding conditions.



Main Features

  • high laser pulse repetition rate (peak) of up to 6 MHz
  • 2x up to 400 scans per second
  • max. measurement range 500 m
  • Eye safe operation at Laser Class 1
  • Field of view 360°
  • Multiple target capability
  • Optional integration of up to 9 cameras
<em>RIEGL</em> VMX-3HA Pointcloud

Main Applications

  • Road Surface Measurement
  • Transportation Infrastructure Mapping
  • City Modeling
  • As-Built Surveying
  • HD Mapping for Autonomous Vehicles
  • Rapid Capture of Construction Sites and Bulk Material
  • GIS Mapping and Asset Management

Technical Data Overview

Effective Measurement Rate 2 x 300 kHz 2 x 1000 kHz 2 x 1800 kHz 2 x 3000 kHz
Max. Range, Target Reflectivity p ≥ 80% 500 m 280 m 250 m 200 m
Max. Range, Target Reflectivity p ≥ 10% 180 m 100 m 90 m 70 m
Minimum Range 1 m 1 m 1 m 1 m
Max. Number of Targets per Pulse 31 15 8 5
Accuracy / Precision 3 mm / 2 mm 3 mm / 2 mm 3 mm / 2 mm 3 mm / 2 mm

Software for RIEGL VMX-3HA

We complement our high-performance hardware with innovative software packages to create powerful solutions for demanding applications. The RIEGL software packages are exclusively bundled with the appropriate RIEGL laser scanners and laser scanning systems. For this RIEGL product we provide:

RiPROCESS

RiACQUIRE

RiUNITE

These RIEGL software packages are complemented by special libraries (RiVLib, RDBLib) and plugins (RiMAP Plugin for ArcGIS).

Explore some selected pointcloud samples.
