RIEGL‘s latest generation of professional Terrestrial Laser Scanners stands out with extreme versatility, high productivity, ultimate performance and additional mobility – providing an excellent return on investment!

The RIEGL VZ-600i offers a broad range capability from 0.5 m up to 1000 m and is suitable for indoor and outdoor 3D mapping applications. 3D position accuracy of 3 mm, less than 30 sec scan time for high-resolution scans with 6 mm point spacing at 10 m, enabling more than 60 scan positions/hour with real-time registration, weight less than 6 kg (13 lbs), 2.2 MHZ PRR, three internal cameras & GNSS integrated, and also prepared for mobile mapping applications – these key features will speed up your workflow in indoor and outdoor applications like AEC (Architecture, Engineering, Construction), BIM (Building Information Modeling), as-built surveying, forensic and crash scene investigation, archeology & cultural heritage documentation, forestry, and many more.

For operating the scanner and for data processing, RIEGL offers the well established software package RiSCAN PRO. Different license levels and plugin module licenses allow an adaption to the user specific requirements.

Special software packages and tools - like RiPANO, that allows to explore your project and to extract plots in your browser - are additionally offered.

For geotechnical analysis of scanned rock surfaces, RIEGL provides the LIS GeoTec Plugin. It facilitates the calculation of surface normal for a local neighborhood. These surface normals are further analyzed to detect clusters of pre-dominant surface orientations, which are used for data classification and visualization on a polarplot diagram.

In forestry applications, the RIEGL LIS TreeAnalyzer Plugin enables the automatic extraction of various individual tree parameters – like georeferenced tree position, tree ID, diameter at breast height, tree height, crown area, or crown diameter – from terrestrial laser point clouds and their further processing in corresponding Third-Party software packages.

Additionally, RIEGL presents four apps for the 3D terrestrial laser scanners of the VZ-i series, which allow real-time analysis and data processing in diverse monitoring applications, among others in land slide monitoring but also in open pit mining operations. Based on reliable real-time data, the Monitoring App, the Monitor+ App, the Design Compare App and the Slope Angle App enable prompt necessary decisions in critical situations. More details about our apps can be found here.

Watch the new RIEGL VZ-600i video here.

Main Features
  • broad range capability (0.5 m up to 1000 m)
  • 5 sec scan time for low resolution overview scans
  • 30 sec scan time for 6 mm resolution @ 10 m distance
  • 60 scan positions per hour (with image acquisition)
  • 3D position accuracy up to 3 mm @ 50 m
  • high laser pulse repetition rate of up to 2.2 MHz
  • scan speed up to 420 lines/sec
  • eye safe operation at Laser Class 1
  • precise real-time onboard registration
  • internal cameras (offering optional on-board face detection and automatic facial blurring in real-time before image storage)
  • internal GNSS receiver / external RIEGL GNSS RTK receiver (optional)
  • optional external system camera or panorama camera
  • weight 6 kg / 13 lbs
  • prepared for mobile use
Main Applications
  • As-Built Surveying
  • Architecture & Facade Measurements
  • Civil Engineering
  • Building Information Modeling (BIM)
  • City Modeling
  • Forensics & Crash Scene Investigation
  • Emergency Management Planning
  • Archeology and Cultural Heritage Documentation
  • Tunnel Surveying
  • Forestry
  • Research
