NEW RIEGL VMX-2HA

The RIEGL VMX-2HA is a High Speed, High Performance Dual Scanner Mobile Mapping System which provides dense, accurate, and feature-rich data at highway speeds. With 2 million measurements and 500 scan lines per second, this turnkey solution is ideally suited for survey-grade mobile mapping applications.

This powerful technology comprises two RIEGL VUX-1HA High Accuracy LiDAR sensors and a high performance INS/GNSS unit, housed in an aerodynamically-shaped protective cover. A camera interface for up to 9 optional cameras enables complementation of the LiDAR data with precisely geo-referenced images. A High-Speed 10 GigE Link allows smooth acquisition of 2 million measurements per second and 9x12 Mpx camera images. Seamless RIEGL workflow for MLS data acquisition, processing and adjustment is provided by RIEGL’s proven software suite.

Main Features
  • High laser pulse repetition rate of up to 2 MHz
  • 500 scan lines per second
  • Range 420 m
  • Eye safe operation at Laser Class 1
  • Field of view 360°
  • Multiple target capability
  • Aerodynamically-shaped protective cover
  • interface for up to 9 optional cameras
  • High-Speed 10GigE link
Main Applications
  • Transportation Infrastructure Mapping
  • Rail Mapping
  • Road Surface Measurements
  • City Modeling
  • Rapid Capture of Construction Sites and Bulk Material
  • Surveying in Open-Pit Mining
  • GIS Mapping and Asset Management
  • As-Built Surveying
